M18 HKP | M18 FORCE LOGIC HYDRAULIC KNOCKOUT PUNCH M18 HUP700
™
™
º FORCE LOGIC ™ hydraulic knockout punch is the most compact and
™
lightweight tool on the market with 60 kN of force M18 HYDRAULIC UTILITY PUMP
º The easiest way to punch - for fast, accurate, round, and burr free holes
º Highest accuracy due to industry’s finest exact alignment system for
dies
º Best balanced tool and easiest control due to one hand operation º FORCE LOGIC ™ hydraulic utility pump powers every single acting
º Quick connector allows easy set-up of punch and die without carrying 700 bar crimping, cutting or punching head attachment
the weight of the tool º Significantly faster work cycles due to a large 1.6 litre total oil reservoir
º Tool punches up to Ø100 mm holes into 3.0 mm mild steel or 2.5 mm and 2x higher flow rate compared to other pumps
stainless steel º The pump is equipped with a industry standard CEJN Series 115, G1/4˝
º Compatible with most common punches and dies available on market female quick connection coupler to suit most common attachments
º Easiest, less strenuous and nonexpendable way of making holes into º 1.8 meter long corded controller enables user to work away from pump
sheet metal and can be extended up to 7 meters with accessory extension cords
º On board fuel gauge and LED light º IP54 rated ingress protection with sealed battery door delivers best
º Brushless motor, REDLITHIUM ™ battery pack and REDLINK ™ electronic protection in harsh environments such as dirt, dust and moisture
deliver power, run time and durability º ONE-KEY ™ tool tracking & security offers a free of charge cloud-based
º Flexible battery system: works with all MILWAUKEE ® M18 ™ batteries tracking network and inventory management platform for your tools.
™
ONE-KEY also features a remote locking functionality. The reporting
function delivers a complete tool activity and accuracy protocol
º Well balanced lifting handle provides even weight distribution for easy
transportation from truck to bucket
º PFM ™ (Predictive Force Monitoring) provides you with instant pressure
verification via a green indicator
º Brushless motor, REDLITHIUM ™ battery pack and REDLINK ™ electronic
deliver power, run time and durability
º Flexible battery system: works with all MILWAUKEE ® M18 ™ batteries
M18 HKP-201C M18 HKP-201CA
Punching force (kN) 60 60
Max. punching diameter (mm) 100 100 M18 HUP700-121
Max. material thickness (mm) 2.5 in stainless and 3.0 in mild steel 2.5 in stainless and 3.0 in mild steel
Weight with battery pack (EPTA) (kg) 2.3 (M18 B2) 2.3 (M18 B2) Max. pressure (bar / PSI) 700 / 10.000
11.1mm ( 7 /16˝) draw stud, 19mm ( 3 /4˝) draw stud, quick connector, ball pull, adaptor, IP protection class 54
Standard equipment 11.1mm ( 7 /16˝) draw stud, 19mm ( 3 /4˝) draw stud, quick connector, ball pull, adaptor Flow rate low pressure (l/min) 2.05
punches and dies: M16, M20, M25, M32, M40
Kit included 1 x M18 B2 Battery pack, M12-18 C Charger, Kitbox 1 x M18 B2 Battery pack, M12-18 C Charger, Kitbox Flow rate high pressure (l/min) 0.42
Article Number 4933451202 4933451204 Coupler type CEJN G1/4"
EAN Code 4002395138906 4002395138920 Total oil volume (l) 1.6
Consumable oil volume (l) 1.3
Weight with battery pack (EPTA) (kg) 16.5 (M18 HB12)
1 x M18 HB12 Battery pack, M12-18 FC
Kit included
Charger, No kitbox or bag supplied
Article Number 4933471813
EAN Code 4058546297121
M18 HKP HYDRAULIC KNOCKOUT PUNCH ACCESSORIES
Description Diameter (mm) Article Number EAN Code Description Diameter (mm) Article Number EAN Code

Punch M16 16.2 4932430841 4002395385034 Die M16 16.2 4932430913 4002395385751

Punch PG16 22.5 4932430843 4002395385058 Die PG16 22.5 4932430915 4002395385775

Punch M20 20.4 4932430842 4002395385041 Die M20 20.4 4932430914 4002395385768

Punch PG21 28.3 4932430845 4002395385072 Die PG21 28.3 4932430917 4002395385799 1.8 meter long corded controller enables user to work Well balanced lifting handle ONE-KEY ™ technology allows linemen to view tool usage,
away from pump receive notifications for recommended maintenance, and
sync information wirelessly to the cloud
Punch M25 25.4 4932430844 4002395385065 Die M25 25.4 4932430916 4002395385782
M18 HUP700 HYDRAULIC PUMP SYSTEM ATTACHMENTS
Punch M32 32.5 4932430846 4002395385089 Die M32 32.5 4932430918 4002395385805
1.8 m extension cord for M18 HUP controller Bucket hanger for M18 HUP700 Replacement oil M18 HUP700
Punch M40 40.5 4932430847 4002395385096 Die M40 40.5 4932430919 4002395385812

Punch M50 50.5 4932430848 4002395385102 Die M50 50.5 4932430920 4002395385829

Punch M63 63.5 4932430849 4002395385119 Die M63 63.5 4932430921 4002395385836

Draw bolt 11.1 mm ( 7 /16˝) 49162680 045242311774 49122775 49122776 4932472004
4058546326487 045242535231 4058546324001
Draw bolt 19 mm ( 3 /4˝) 49162681 045242311781
