WWW.MILWAUKEETOOL.EU MILWAUKEETOOLEU

AS 2-250 ELCP | 25 L L-CLASS DUST EXTRACTOR MSL 1000 | MITRE SAW STAND EXTENDABLE UP TO 2 M
º Large 25 litre tank capacity ideal for workshop use AS 2-250 ELCP º Light weight aluminium, easy to transport onto the job site MSL 1000
º 1000 W motor power with over 210 mbar suction - 10% more efficient º 1.08 m total length, will fit into most small vans and cars
º Power take off with auto switching for powertools Power input (W) 1000 º Extendable each side - 2.08 m extended Height (mm) 850
º 2600W power take off capacity allows for use with high wattage tools Air volume (l/min) 3600 º Will hold up to 180 kg Base size (mm) 1065
º Clear press filter cleaning system maintains suction efficiency Max. vacuum (mbar) 210 º One point leg adjustment for leveling on uneven ground Extendable up to (mm) 2125
º Washable PET filter provides longer filter life Capacity (l) 25 º Quick release brackets Collapsed size (mm) 1065
º Dust class L. Standard MAK-factor > 1 mg/m³ Hose diameter (mm) 32 º Height adjustable length stops Bearing force (kg) 180
º Wet and dry capability Weight (kg) 10.4 º Compact foldable design Weight (kg) 17.0
º Hose and cable storage enables easy transportation Supplied in No kitbox or bag supplied Supplied in No kitbox or bag supplied
º Dust blower function Article Number 4933447480 Article Number 4933428970
º 7.5 m rubber cable EAN Code 4002395006274 EAN Code 4002395241729
º Supplied with 3.5 m hose with floor cleaning kit, PET filter, 2x powertool
connection adaptor, 1x disposable bag, 1x fleece bag & 1x crevice
nozzle

MS 304 DB MSL 2000 | MITRE SAW STAND EXTENDABLE UP TO 2.5 M

º Light weight aluminium, easy to transport onto the job site
12˝ (305 MM) DUAL BEVEL SLIDING MITRE SAW º 1.09 m total length, will fit into most small vans and cars MSL 2000
º Extendable each side - 2.54 m extended Height (mm) 860
º Will hold up to 227 kg Base size (mm) 1093
º One point leg adjustment for leveling on uneven ground Extendable up to (mm) 2542
º 1800 Watt direct drive motor ensures a quick, clean cut even in º Quick release brackets Collapsed size (mm) 1093
hardwood materials º Height adjustable length stops Bearing force (kg) 227
º Dual integral jobsite lights illuminate the cut line º Compact foldable design with quick release latches Weight (kg) 14.0
º Integral dust channel captures 75% of all dust by capturing dust near
the cut on both sides of the blade and directing it to the back of the saw Supplied in No kitbox or bag supplied
º Unique inline motor design - for excellent visibility from both sides to the Article Number 4933459617
work piece and better balanced transport EAN Code 4058546027896
º Mitre capacity 55° to the left and 60° to the right – for maximum
versatility. Mitre detents L & R at: 0°, 15°, 22.5°, 31.6°, 45°, 60°
º Dual-bevel design – to incline the saw head left and right 0° – 48° with
bevel detents L & R at: 0°, 22.5°, 33,85°, 45°, 48°
º Fast and accurate bevel adjustment
º Supplied with Work piece clamp, saw blade (60 teeth), vacuum adaptor
Ø35 / 58 mm, wrench and 3 m cable

MSUV 280 | MITRE SAW STAND EXTENDABLE UP TO 2.8 M
º Upright folding design for easy storage and transportation MSUV 280
º Easy one action foot pedal lock and single lift point allows the stand to
be quickly setup with a mitre saw attached Height (mm) 850
º Universal quick release saw brackets compatible with all MILWAUKEE ® Base size (mm) 1160 x 650
MS 304 DB mitre saws Extendable up to (mm) 2800
Power input (W) 1800 º Extra wide work piece support rollers allows larger materials to be more Collapsed size (mm) 1320 x 650 x 630
No load speed (rpm) 3900 easily handled Bearing force (kg) 136
Blade diameter (mm) 305 º 2.8 m extension width Weight (kg) 27.0
Bevel capacity left (°) 48 º 136 kg maximum load capacity Supplied in No kitbox or bag supplied
º Integrated storage tray
Bevel capacity right (°) 48 º Large wheels for ease of transportation over uneven surfaces Article Number 4933478992
Mitre capacity left (°) 55 EAN Code 4058546362744
Mitre capacity right (°) 60
Max. cutting capacity 45° mitre/ 45° bevel (mm) 241 x 57 305 X 30 MM 60 TOOTH CIRCULAR SAW BLADE
Max. cutting capacity 45° mitre/ 90° bevel (mm) 241 x 102 WITH 3.0 MM CUTTING WIDTH
Max. cutting capacity 90° mitre/ 45° bevel (mm) 342 x 57
Max. cutting capacity 90° mitre/ 90° bevel (mm) 342 x 102 Article Number 4932471321
Weight (kg) 29.5
Supplied in No kitbox or bag supplied
Article Number 4933471052
EAN Code 4058546286804
MS 216 | 8 ½˝ (216 MM) SLIDING MITRE SAW MSL 3000 | MITRE SAW STAND EXTENDABLE UP TO 3 M
º 1800 Watt motor for high performance cutting in hard timber MS 216 SB º Lightweight construction and wheel set - provides portability on the MSL 3000
º Durability - dual vertical steel rails with linear bearings deliver smooth jobsite
sliding action Power input (W) 1800 º Folds down to 1200 mm - thanks to the collapsible legs and compact Height (mm) 810
º Rail lock - the saw head locks in the back position automatically No load speed (rpm) 6000 design Base size (mm) 1100
º Adjustable laser - for perfect and quick alignment to cut line Blade diameter (mm) 216 º Extendable up to 3 m - makes it easy to cut large workpieces to length Extendable up to (mm) 3000
º Steel detent plate with preset angles - gives repeatable accurate cuts Bevel capacity left (°) 48 º Heavy Duty - carries up to 250 kg Collapsed size (mm) 1200
º Lock lever/handle over mold - allows the user to make repeated cuts Bevel capacity right (°) -2 º One point leg adjustment for leveling on uneven ground Bearing force (kg) 250
comfortably and without fatigue Mitre capacity left (°) 50 º Comfortable working height at 81 cm Weight (kg) 23.0
º Mitre release system - for quick and smooth change of cutting Mitre capacity right (°) 50 º Fully adjustable work piece rests - provide support for long lengths of Supplied in No kitbox or bag supplied
orientation Max. cutting capacity 45° mitre/ 45° bevel (mm) 190 x 48 material – single knob adjustment Article Number 4933411565
º Integral LED jobsite light Max. cutting capacity 45° mitre/ 90° bevel (mm) 190 x 60 º Quick to assemble - set up within seconds EAN Code 4002395236213
º Spindle lock - for quick and easy blade change Max. cutting capacity 90° mitre/ 45° bevel (mm) 270 x 48 º Roller supports - for effective material support
º Heavy duty cast base and fence ensures durability and accuracy Max. cutting capacity 90° mitre/ 90° bevel (mm) 270 x 60
º 48°/-2° bevel capacity Bore size (mm) 30
º Supplied with saw blade (48 teeth), blade spanner and work clamp
Weight (kg) 14.5
Supplied in No kitbox or bag supplied
Article Number 4933471055
EAN Code 4058546286835

200 For further technical specifications, including noise and vibration data, please visit our website: www.milwaukeetool.eu For further technical specifications, including noise and vibration data, please visit our website: www.milwaukeetool.eu 201
