WWW.MILWAUKEETOOL.EU MILWAUKEETOOLEU
LASERS RANGE M12 3PL | M12 GREEN 360° 3 PLANE LASER
™
º M12 ™ green 360° 3 plane laser provides an all-in-one functionality with
one horizontal line and two vertical lines for fast and easy alignment, M12 3PL-0C M12 3PL-401C M12 3PLKIT-401P
leveling, squaring, and transfers allowing you to easily layout large Colour of laser line Green Green Green
spaces with one tool 2x vertical, 1x 2x vertical, 1x 2x vertical, 1x
º Built with high intensity green diodes to provide maximised visibility - up Laser projection horizontal horizontal horizontal
to 4x better visibility vs red lasers Working range visible (m) 38 38 38
º High intensity green beams provide a working range of 38 m and up to Accuracy (mm/m) 0.3 0.3 0.3
100 m with a detector Self-levelling range (°) 4 4 4
º Provides all-day run time of 15+ hours with an M12 B4 battery pack Compatible laser detector LLD50 / LRD100 LLD50 / LRD100 LLD50 / LRD100
º 3 mode pendulum system: Manual Mode for use at any angle, Self- Weight with battery pack
Levelling Mode that indicates out-of-level condition with a 4° self- (EPTA) (kg) 1.5 (M12 B4) 1.5 (M12 B4) 1.5 (M12 B4)
levelling range and Pendulum Lock Mode to protect components during HIVIST, LLD50,
transport Standard equipment Track clip, HIVIST Track clip, HIVIST LM360, TRP120,
º Integrated magnetic bracket with rear mounted amplified rare earth Track Clip
magnets, /4˝ and 5 /8˝ tripod thread and hang hole - allows attachment to No batteries 1 x M12 B4 1 x M12 B4
1
steel stud, wooden stud and tripod
º The bracket also provides the laser 330° rotation that pivots on plumb Kit included supplied, No Battery pack, Battery pack,
C12 C Charger,
charger supplied, C12 C Charger,
point, with an integrated micro control knob for faster point to point
alignment Kitbox Kitbox PACKOUT ™ box
º Robust over-moulded construction with an IP 54 rating, the laser is Article Number 4933478103 4933478102 4933478960
4058546340360 4058546340353 4058546362423
EAN Code
water/ debris resistant and can withstand up to 1 m drops
º Flexible battery system: works with all MILWAUKEE ® M12 ™ batteries
M12 CLLP | M12 GREEN CROSS LINE LASER WITH PLUMB POINTS
™
º M12 ™ green cross line laser with plumb points provides an all-in-one
functionality with horizontal levelling, vertical alignment and plumb point M12 CLLP-0C M12 CLLP-301C
transfer from floor to ceiling 1x horizontal, 1x 1x horizontal, 1x
º Built with high intensity green diodes to provide maximised visibility - up Laser projection vertical, 2x plump vertical, 2x plump
to 4x better visibility vs red lasers points points
º High intensity green beams provide a working range of 38 m and up to Working range visible (m) 38 38
100 m with a detector Accuracy (mm/m) 0.3 0.3
º Provides all-day run time of 15+ hours with an M12 B3 battery pack Self-levelling range (°) 4 4
º 3 mode pendulum system: Manual Mode for use at any angle, Self- Compatible laser detector LLD50 / LRD100 LLD50 / LRD100
Levelling Mode that indicates out-of-level condition with a 4° self- Weight with battery pack (EPTA) (kg) 1.2 (M12 B3) 1.2 (M12 B3)
levelling range and Pendulum Lock Mode to protect components during Standard equipment Track clip, HIVIST Track clip, HIVIST
transport
º Integrated magnetic bracket with rear mounted amplified rare earth No batteries supplied, 1 x M12 B3 Battery
magnets, 1 /4˝ and 5 /8˝ tripod thread and hang hole - allows attachment to Kit included No charger supplied, pack, C12 C Charger,
steel stud, wooden stud and tripod Kitbox Kitbox
º The bracket also provides the laser 360° rotation that pivots on plumb Article Number 4933478101 4933478100
point, with an integrated mico control knob for faster point to point EAN Code 4058546340346 4058546340339
alignment
º Robust over-moulded construction with an IP 54 rating, the laser is
water/debris resistant and can withstand up to 1 m drops
º Flexible battery system: works with all MILWAUKEE ® M12 ™ batteries
º Includes 1x high visibility target plate and 1x track clip
L4 CLLP | USB RECHARGEABLE GREEN CROSS LINE LASER WITH PLUMB POINTS TM
º REDLITHIUM ™ USB rechargeable green cross line laser with plumb L4 CLLP-301C
points provides an all-in-one functionality with horizontal levelling,
vertical alignment and plumb point transfer from floor to ceiling Laser projection 1x horizontal, 1x vertical, 2x plump points
º Built with high intensity green diodes to provide uncompromised visibility Working range visible (m) 30
- up to 4x better visibility vs red lasers Accuracy (mm/m) 0.3
º High intensity green beams provide a working range of 30 m and up to Self-levelling range (°) 4
100 m with a detector Compatible laser detector LLD50 / LRD100
º The rechargeable and removable REDLITHIUM ™ USB 3.0 Ah battery Weight with battery pack (EPTA) (kg) 0.90 (L4 B3)
provides all day run time of over 8 hours Standard equipment Track clip
º 1x REDLITHIUM ™ USB 3.0 battery replaces up to 6,000 alkaline batteries 1 x L4 B3 Battery pack, USB cable and wall
over the lifetime of the battery Kit included plug, Kitbox
º 3 mode pendulum system: Manual Mode for use at any angle, Self- Article Number 4933478099
Levelling Mode that indicates out-of-level condition with a 4° self- EAN Code 4058546340322
levelling range and Pendulum Lock Mode to protect components during
transport
º Integrated magnetic bracket with rear mounted amplified rare earth
1
magnets, /4˝ tripod thread and hang hole - allows attachment to steel
stud, wooden stud and tripod
º The bracket also provides the laser 360° rotation that pivots on plumb
point, with an integrated micro control knob for faster point to point
alignment
L4 CLL | USB RECHARGEABLE GREEN CROSS LINE LASER TM
º REDLITHIUM ™ USB rechargeable green cross line laser provides an all- L4 CLL-301C
in-one functionality with horizontal levelling and vertical alignment
º Built with high intensity green diodes to provide uncompromised visibility Laser projection 1x vertical, 1x horizontal
- up to 4x better visibility vs red lasers Working range visible (m) 30
º High intensity green beams provide a working range of 30 m and up to Accuracy (mm/m) 0.3
100 m with a detector Self-levelling range (°) 4
º The rechargeable and removable REDLITHIUM ™ USB 3.0 Ah battery Compatible laser detector LLD50 / LRD100
provides all day run time of over 8 hours Weight with battery pack (EPTA) (kg) 0.90 (L4 B3)
º 1x REDLITHIUM ™ USB 3.0 battery replaces up to 6,000 alkaline batteries Standard equipment Track clip
over the lifetime of the battery 1 x L4 B3 Battery pack, USB cable and wall
º 3 mode pendulum system: Manual Mode for use at any angle, Self- Kit included plug, Kitbox
Levelling Mode that indicates out-of-level condition with a 4° self- Article Number 4933478098
levelling range and Pendulum Lock Mode to protect components during EAN Code 4058546340315
transport
º Integrated magnetic bracket with rear mounted amplified rare earth
magnets, 1 /4˝ tripod thread and hang hole - allows attachment to steel
stud, wooden stud and tripod
º The bracket also provides the laser 360° rotation, with an integrated
micro control knob for faster point to point alignment
º Robust over-moulded construction with an IP 54 rating, the laser is
water/ debris resistant and can withstand up to 1 m drops
90 For further technical specifications, including noise and vibration data, please visit our website: www.milwaukeetool.eu 91
