WWW.MILWAUKEETOOL.EU MILWAUKEETOOLEU

LASER ATTACHMENTS LDM 100 | 100 M LASER DISTANCE METER

º Easy to use one person point and shoot system LDM 100
Description Article Number EAN Code º IP54 water & dust protection
º Metric & Imperial units of measurement Max. measurement range (m) 100
º Easy to touch measure buttons on the front and side of the housing to Accuracy ±1,5
perform single measurements & continuous tracking Display LCD
º Offers several different measurement functions that allow users to add Display size (mm) 31.5 x 40
º The MILWAUKEE ® LLD50 laser line detector extends laser line functionality up and subtract values, calculate linear distance, surface area, total area Laser classification Class 2
to 50 metres and volume Dimensions (mm) 113 x 48 x 31
º The LEDs on front and back allow easy and accurate detection of the laser beam º Digital auto-level feature allows for a measurement to be automatically Range (m) 0.15 - 100
to improve the set-up process taken when the meter reaches a level position (0°), increasing accuracy Weight with battery pack (EPTA) (kg) 0.14 (2 x AAA)
º Rare earth magnets located on two sides of the detector allow it to easily attach when measuring long distances Auto-level measurements Yes
to metal surfaces, ideal for suspended ceiling installations º Easy indirect height and length measurement using the auto-level Pythagoras function Yes
º The included clamp is ideal for attaching to non-metal surfaces for setting feature to enhance user convenience in difficult measurement situations
LLD50 Laser line detector elevations 4932478104 4058546340377 º Large 3 line 50 mm diameter multi-color LCD graphical display for Inclination sensor Yes
º The detector has adjustable audio feedback and has over 65 hours of run time optimised visibility Height tracking Yes
with included AA batteries º Display shows last three measurements and history menu shows the last Kit included 2 x AAA Batteries, No kitbox or bag
º Compatible with all MILWAUKEE ™ line & plane lasers 30 calculations supplied
º Adjustable accuracy settings for greater precision º Built-in 3-position auto-reference fold out pin for easy in corner/edge Article Number 4933459278
º IP54 protects detector from jobsite conditions measurements EAN Code 4058546002442
º 1 m impact resistance º Auto shut off and low power indication
º Slim housing for easy handling and nylon carry pouch for safe transport
º The MILWAUKEE ® LRD100 detector extends laser line functionality up to 100 LDM 50 | 50 M LASER DISTANCE METER
metre in combination with all MILWUAKEE cross line and plane lasers and can
®
be universally used with rotary lasers up to 250 metre radius º Easy to use one person point and shoot system LDM 50
º The millimetre display on front and back allows easy and accurate detection of º Very slim housing design with belt clip for easy transport
the laser beam to improve the set-up process º Area/volume/indirect height and patent pending surface measurement Max. measurement range (m) 50
º Red and green laser diodes detection for most versatile use º Min/Max sweep & continuous tracking Accuracy ±1.5
Line/ rotary laser º Supplied with 1x AA battery and a material clamp to attach to rod, stud, pipe or º Distance addition & subtraction for layouting Display LCD
LRD100 levels for setting elevation 4932479555 4058546373498 º Indirect height measurements (Pythagoras 2-point, 3-point, partial Display size (mm) 26 x 37
detector height)
º IP67 rated for dust and water protection Laser classification Class 2
º Strong magnets located on top of the detector allow it to easily attach to metal º Large 3 line LCD graphical display with automatic white backlight Dimensions (mm) 119 x 40 x 32
surfaces, ideal for suspended ceiling installations º Fold-out end piece for diagonal corner measurements Range (m) 0.05 - 50
º 5 mode adjustable accuracy settings for setting up the laser detector specifically º Memory recall for the last 20 measurements Weight with battery pack (EPTA) (kg) 0.1 (2 x AAA)
to the application º IP54 water & dust protection Pythagoras function 2-point, 3-point, partial height
º LED & audio indication to align from distance º Auto shut off and low power indication Inclination sensor No
º Adjustable centre line for more efficient laser setup º Metric units of measurement only Height tracking No
2 x AAA Batteries, No kitbox or bag
Kit included
supplied
Article Number 4933447700
EAN Code 4002395006540
º The MILWAUKEE ® 360° laser mount is an adaptable laser attachment that
provides the fastest laser setup
º Multi-plane rotational adjustment, users can easily attach all MILWAUKEE ® lasers
to the mount
LM360 360° laser mount º A micro vertical adjustment that makes aligning horizontal lines much faster 4932478105 4058546340384
º The amplified rare earth magnets on both sides provide a strong hold even on
thin steel stud material
º Integrated screw and nail hang holes make setup easy and efficient in any
environment LDM 45 | 45 M LASER DISTANCE METER
º Integrated 1 /4˝ & 5 /8˝ thread to easily attach to most tripods
º Easy to use one person point and shoot system LDM 45
º IP54 water & dust protection
º Metric & Imperial units of measurement Max. measurement range (m) 45
º The MILWAUKEE ® high visibility laser target plate provides fast and visible º Easy to touch measure buttons on the front and side of the housing Accuracy ± 1.5
High visibility laser alignment with a wide magnetic base for floors & ferrous surfaces º Enables user to perform single measurements & continuous tracking Display LCD
HI-VIST º High contrast reflective surface for use with green lasers 4932478108 4058546340414 º Offers several different measurement functions that allow users to add Display size (mm) 31.5 x 40
target plate and subtract values, calculate linear distance, surface area, total area
º The X design provides responsive centering feedback that guides the line to the Laser classification Class 2
centre, making the alignment process faster and volume Dimensions (mm) 105 x 48 x 24
º Large 3 line 50 mm diameter multi-color LCD graphical display for Range (m) 0.15 - 45
optimised visibility Weight with battery pack (EPTA) (kg) 0.11 (2 x AAA)
º Display shows last three measurements and history menu shows the last Auto-level measurements No
30 calculations Pythagoras function No
º Built-in 2-position auto-reference fold out pin for easy in corner Inclination sensor No
measurements Height tracking No
º Auto shut off and low power indication 2 x AAA Batteries, No kitbox or bag
º Slim housing for easy handling and nylon carry pouch for safe transport Kit included
º The MILWAUKEE ® laser tripod with a 1/4" mounting thread is ideal for setting supplied
the height of a horizontal laser line or elevating the laser when needed Article Number 4933459277
º Height can be adjusted easily from 72 cm to 180 cm EAN Code 4058546002435
º Laser can be mounted to the bottom of the tripod with the 360° mount (not
TRP180 1.8 meter laser tripod included) for low level applications like socket installation 4932478106 4058546340391
º Adjustable pan tilt head with removable laser mounting plate
º Reinforced gearing on the centre shaft for longer tool life
º Light weight aluminium design
LDM 30 | 30 M LASER DISTANCE METER
º Easy to use one person point and shoot system LDM 30
º IP54 water & dust protection
º Auto shut off and low power indication Max. measurement range (m) 30
º Metric & Imperial units of measurement Accuracy ± 2
º Very slim housing design with belt clip for easy transport Display LCD
º Two easy to touch measure buttons on the front and side of the housing Display size (mm) 25 x 25
º Enables user to perform single measurements & continuous tracking Laser classification Class 2
º Large 3 line LCD graphical display with automatic white backlight Dimensions (mm) 101 x 38 x 28
º The MILWAUKEE ® compact laser tripod with a 1 /4˝ mounting thread and a flat º Display shows last three measurements Range (m) 0.15 - 30
head design is ideal for setting the height of a horizontal laser line or elevating Weight with battery pack (EPTA) (kg) 0.10 (2 x AAA)
the laser when needed Auto-level measurements No
TRP120 1.2 meter compact º Height can be adjusted easily from 47 cm to 120 cm 4932478959 4058546362416 Pythagoras function No
laser tripod º 29 cm elevating range for fine adjusting the height Inclination sensor No
º Laser can be mounted to the bottom of the tripod with the LM360 bracket (not Height tracking Yes
included) for low level applications like socket installation Kit included 2 x AAA Batteries, Blister packaging
º Durable and light weight aluminium frame for a longer life Article Number 4933459276
EAN Code 4058546002428
