SYSTEM ATTACHMENTS - WET DIAMOND DRILLING FIXTEC SOLUTION WITH DUST EXTRACTION
™

Description Tool reception Core reception Article Number EAN Code
Fits DCM2-250C &
Description Fits DD3-152 Fits MXF DCD150 Article Number EAN Code
DCM2-350C
Fixing kit. For exclusive use in concrete. Ø 16 mm drill bit is
required to set the drop anchor
FIXTEC™ Clean Line Rotor (CLR) M18 x 2.5 1 ¼˝ UNC 4932352172 4002395368242
✔ ✔ ✔ 4932399731 4002395363827
Stud bolt, setting tool, wing nut, washer and 5 pcs M12 drop
anchor
1 3 /8˝ open ended spanner. For holding the motor output spindle ✔ 49964705 045242222766
while removing a core bit
32 mm ended spanner. For holding the motor output spindle
while removing a core bit. ✔ 4931428009 4002395844791

41 mm open ended spanner. For removing the core bit from the ✔ ✔ 4931428010 4002395844807
motor spindle.

FIXTEC SOLUTION WITHOUT DUST EXTRACTION
™
Fixtec release. Suitable for all diamond motors with 1 1 /4˝ spindle
reception. Prevents the core bit from locking itself too tight onto
the machine spindle. The core bits can then be released and ✔ ✔ 4932352053 4002395367108
removed with minimum effort Description Tool reception Core reception Article Number EAN Code
1 1 /4˝ female to 1 /2˝ female adaptor: To enable the connection of ✔ ✔ 4932352627 4002395372850
<50 mm diamond core bits on a 1 1 /4˝ machine spindle thread
M18 x 2.5 M16 4932399174 -MISSING-
1 1 /4˝ female / male extention rod, length 300 mm ✔ ✔ ✔ 4932399724 4002395363759
FIXTEC™ adaptor. Tool changing in
1 1 /4˝ female / male extention rod, length 500 mm ✔ ✔ ✔ 4932399725 4002395363766 seconds. No extra tool required

Telescopic extention. Extension pole used to fix drill rig to the
ground instead of anchor bolts. Maximum load of 500 kg and ✔ ✔ ✔ 4932399732 4002395363834 11 mm Hex M16 4932399220 4002395358342
adjustable extension height from 1.8-2.9 m

Vacuum pump VP6: For fastening of the diamond drill rig on
smooth and even surfaces. Suction capacity: 850 mbar. Max. ✔ ✔ ✔ 4932352094 4002395367474
vacuum pressure: 6 m³/h / 100 l/min. Rated voltage: 220-240 V

Vacuum plate. Replacement rubber seal 4931428665 ✔ 4932352676 4002395373345
GUIDE RODS FOR DIAMOND CORE DRILLS

WT 10 watertank. 10 liters capacity, steel, water tank with inside Description Article Number EAN Code
and outside polyester coating. Reliable brass pump with a max. ✔ ✔ ✔ 4932399726 4002395363773
pressure bar of 6 bar. 2.5 m hose with quick connection system
fits direct to Milwaukee® diamond drills
Guide rod for DD2-160. Supplied with locking screw (4931622432). Re-
quires allen key (4931616044) and SDS-plus pilot drill bit (Ø 8 x 160 mm, 4932399173 4002395357802
4932307071)
Water collection ring: For use with drill rig DR 152 T. For use with max. Ø 152 mm core bits 4932352677 4002395373352
Replacement rubber ring for DR 152 T 4932352678 4002395373369
Water collection ring: For use with drill rig DR 250 TV. For use with max. Ø 180 mm core bits ✔ 4932399727 4002395363780
Replacement rubber ring for DR 250 TV ✔ 4932399729 4002395363803
Water collection ring: For use with drill rig DR 350 T. For use with max. Ø 300 mm core bits 4932399728 4002395363797 Guide rod for DD3-152. Requires SDS-plus pilot drill bit (Ø 8 x 110 mm,
4932307070) 4932352679 4002395373376
Replacement rubber ring for DR 350 T 4932399730 4002395363810

Spacer block T = 50 mm. Needs to be mouted between drill rig
and motor cores > 250 mm and max. 350 mm. Included in drill ✔ 4932399736 4002395363872
rig DR 350 T

Quick connection motor mounting plate. Included in both drill ✔ 4932399733 4002395363841
rigs DR 250 TV and DR 350 T

Water collection ring: For universal use with diamond drilling ✔ ✔ ✔ 4932478073 4058546340063
tools. For use with max. Ø 152 mm core bits
